Raymarine A80011 B265 Chirp-Lm Thru-Hull Transducer

Description

Attributes

• Mounting Location: Thru-Hull Mount
• Depth: 3000 Feet At Low Frequency/ 1500 Feet At Medium Frequency
• Power Rating: 1000 Watt
• Frequency Range: 42 To 65 kHz Low/ 85 To 135 kHz Medium CHIRP
• Supported Angle: 25 To 16 Degree Low Beam Width/ 16 To 11 Degree Medium Beam Width
• Cable Length: 33 Feet

Product Description

With up to 103 Kilohertz of CHIRP range and 8 internal ceramics this transducer has the ability to provide great target separation in both shallow and deep water. B265 comes in either a Low/High (LH) configuration or a Low/Medium (LM) configuration. The medium element will provide better shallow water coverage under the vessel, while the high element will provide better shallow water resolution. Use the low element for deep-water detection of bottom and fish as deep as 3,000 Meter.

Features & Benefits

• Transducer Has The Ability To Provide Great Target Separation In Both Shallow And Deep Water
• Medium Element Will Provide Better Shallow Water Coverage Under The Vessel, While The High Element Will Provide Better Shallow Water Resolution
• High Performance Fairing Improves Broadband Performance At Speeds Over 30 Knots
• Easy To Install
• Limited 2 Year Warranty
